| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Remote viewing | Yes |
| Processor model | ARM Cortex-A53 |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Indoor & outdoor |
| Cable length | 0.3 m |
| Built-in light | Yes |
| Built-in processor | Yes |
| Design |
|---|
| Weatherproof | Yes |
| IK code | IK10 |
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling/wall |
| Protection features | Vandal proof |
| LED indicators | Yes |
| International Protection (IP) code | IP66 |
| Housing material | Aluminium, Polycarbonate (PC) |
| Camera |
|---|
| Lens viewing angle, horizontal | 109.9° |
| Lens viewing angle, vertical | 56.7° |
| Lens viewing angle, diagonal | 134.1° |
| Image sensor |
|---|
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Lens system |
|---|
| Number of lenses | 1 |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 40 m |
| LED type | IR |
| Video |
|---|
| Image quality adjustment | Brightness, Colour depth, Contrast, DNR, Sharpness |
| Text caption overlay | Yes |
| Privacy masking | Yes |
| Maximum resolution | 3840 x 2160 pixels |
| Supported video modes | 2160p |
| Frame rate | 30 fps |
| Total megapixels | 8 MP |
| Audio |
|---|
| Built-in microphone | Yes |
| Network |
|---|
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Storage |
|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Light sensor | Yes |
| Management features |
|---|
| Web-based management | Yes |
| Reset button | Yes |
| Smartphone/tablet remote support | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 10 W |
| DC output voltage | 42.5, 57 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| System requirements |
|---|
| Mobile operating systems supported | Android, iOS |
| Weight & dimensions |
|---|
| Height | 90.8 mm |
| Diameter | 11.8 cm |
| Weight | 700 g |
| Cable length | 0.3 m |
| Features |
|---|
| License plate recognition | Yes |
| Sustainability |
|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Packaging content |
|---|
| Number of cameras | 1 |
| Screws included | Yes |
| Mounting kit | Yes |
| Technical details |
|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
