| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Remote viewing | Yes |
| Processor model | ARM Cortex-A53 |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Indoor & outdoor |
| Built-in processor | Yes |
| Design |
|---|
| Weatherproof | Yes |
| IK code | IK08 |
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling/wall |
| Protection features | Vandal proof |
| LED indicators | Yes |
| International Protection (IP) code | IPX4 |
| Housing material | Aluminium, Polycarbonate (PC), Stainless steel |
| Camera |
|---|
| Field of view (FOV) angle | 360° |
| Image sensor |
|---|
| Sensor type | CMOS |
| Lens system |
|---|
| Number of lenses | 1 |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 9 m |
| LED type | IR |
| Video |
|---|
| Image quality adjustment | Brightness, Colour depth, DNR, Sharpness |
| Text caption overlay | Yes |
| Maximum resolution | 1920 x 1920 pixels |
| Video compression formats | H.264, M-JPEG |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 5 MP |
| Audio |
|---|
| Built-in speaker(s) | Yes |
| Built-in microphone | Yes |
| Audio system | 2-way |
| Network |
|---|
| Bluetooth | No |
| Ethernet interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.3af |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Storage |
|---|
| Flash memory | 8000 MB |
| RAM capacity | 2000 MB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Management features |
|---|
| Web-based management | Yes |
| Reset button | Yes |
| Smartphone/tablet remote support | Yes |
| Power |
|---|
| Power source type | PoE |
| Power consumption (max) | 8.64 W |
| Operational conditions |
|---|
| Operating temperature (T-T) | -20 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| System requirements |
|---|
| Mobile operating systems supported | Android, iOS |
| Weight & dimensions |
|---|
| Height | 49 mm |
| Diameter | 14.7 cm |
| Weight | 655 g |
| Sustainability |
|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Packaging content |
|---|
| Number of cameras | 1 |
| Manual | Yes |
| Technical details |
|---|
| Voltage | 37 - 57 V |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Other features |
|---|
| Video compression formats | H.264, M-JPEG |
