| Performance |
|---|
| Languages support | Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Dynamic range | 110 dB |
| Design |
|---|
| IK code | IK08 |
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling |
| International Protection (IP) code | IP66 |
| Camera |
|---|
| Minimum illumination | 0 lx |
| Tilt angle range | 0 - 60° |
| Pan range | -180 - 180° |
| Angle of rotation | 95° |
| Camera shutter speed | 1/25000 - 2 s |
| Lens viewing angle, horizontal | 110° |
| Lens viewing angle, vertical | 60° |
| Image sensor |
|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Lens system |
|---|
| Detect distance | 40 m |
| Observe distance | 15.9 m |
| Recognize distance | 8 m |
| Identify distance | 4 m |
| Fixed focal length | 2.9 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 20 m |
| LED type | IR |
| Video |
|---|
| Maximum resolution | 1920 x 1080 pixels |
| Video compression formats | H.264, H.265, M-JPEG |
| Frame rate | 60 fps |
| Total megapixels | 2 MP |
| Audio |
|---|
| Signal-to-Noise Ratio (SNR) | 55 dB |
| Network |
|---|
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSb , HTTP/2, TLSb , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Storage |
|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD |
| Built-in HDD | No |
| Internal memory | 1024 MB |
| Flash memory | 512 MB |
| Ports & interfaces |
|---|
| Connectivity technology | Wired |
| Power |
|---|
| Power source type | PoE |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 50 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 100% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions |
|---|
| Weight | 390 g |
| Packaging content |
|---|
| Number of cameras | 1 |
| Other features |
|---|
| Video compression formats | H.264, H.265, M-JPEG |
