| Panel |
3 x 0.63 " TFT p-Si (4:3), micro lens |
| Lamp |
175W UHP (LMP-123) |
| Brightness |
2500 ANSI lumens |
| Lamp life |
3500 h (eco mode) / 2000 h (normal mode) |
| Fan noise |
30 dB (eco mode) / 34 dB (normal mode) |
| Standard lens |
F = 1.77 - 1.99 / f = 17.4 - 21.1 mm |
| Contrast ratio |
500:1 |
| Resolution in pixels |
1024 x 768 (XGA) |
| Uniformity |
85% |
| Colour system |
PAL, SECAM, NTSC, NTSC4.43, PAL-M, PAL-N |
| Connections Input |
| |
Input 1: D-Sub15 (RGB) |
| |
Input 2: D-Sub15 (RGB) or Monitor Out |
| |
Input 3: RCA (Composite) |
| |
Audio: 3.5mm Stereo Jack for Computer |
| |
Audio: 2 x RCA (R/L mono) for video |
| |
Control Input Jack : Mini-DIN 8-pin (RS232 compatible) |
|
| Audio function |
1W Mono |
| Keystone correction |
vertical +/- 20 |
| Up/down ratio |
Up/Down Ratio 6:1 (Fixed U/D Ratio) |
| Zoom/focus |
1.2x/manual focusing |
| Power consumption |
| |
188 W (eco mode) / 219 W (normal mode) |
| |
3.8 W (stand-by mode) |
|
| Voltage |
100 - 240 V |
| Operating temperature |
5C - 35 C |
| Storage temperature |
-10C - 60 C |
| Dimensions (W x H x D) |
265 x 74 x 189 mm |
| Weight (Net) |
1.6kg |
| Weight (Gross) |
3.7kg |
| Packaging Dimensions (WxHxD) |
382 x 195 x 380 mm |
| Standard accessories |
Remote control, Batteries, User manual (CD-ROM), Power cable, PIN code label, Carry bag, Lens cover, power cord |
