| Panel |
0.95 SXGA+ DLP chip x 1 |
| No. of pixels |
1,470,000 (1400 x 1050 dots) |
| Projection lamp |
330W VIDI UHP x 2 |
| Brightness (typical) |
7,500 lm (with LNS-S50, Dynamic image, DynamicBlack Off) |
| Contrast |
7,500:1 (with DynamicBlack High) |
| Uniformity |
90% (corner to center) |
| Image setting |
Lens shift Vertical: 21:-1 ~ -1:21, Horizontal: 19:1 ~ 1:19, Digital Keystone :U/D/R/L |
| Optional lens |
LNS-W52/W51/W50/S50/T50/T51 (Throw ratio: 0.87, 1.30-8.63) |
| Colour wheels |
Standard: 4seg RGBW for high brightness x 2
Standard accessory: 6seg RGBCMY for rich color reproduction x 2 |
| Other features |
DICOM simulation, Picture in Picture & Picture by Picture, Mechanical lens shutter, DynamicBlack(auto iris according to image), BrilliantColor, VIDI UHP lamp variable illumination, Full 10bit circuit, Auto picture control, Color management |
| Signal terminal |
Input 1: RGB(D-Sub15), DVI- D(HDCP), HDMI(v1.3 with Deep Color)
Input 2: RGBHV, Y,Pb/Cb, Pr/Cr, Video(BNC), S-Video
Input 3: Detachable terminal for system up
Input 4: Detachable terminal (NETWORK POA-MD13NET2)
Output: RGB(D-sub15) - Analog input only |
|
| Optional terminal |
Warp & Blending, Dual-SDI, DVI, 5BNC, D-sub15 |
| Control port |
RJ-45 wired LAN (POA-MD13NET2), D-sub9pin (RS232C) In/Out, Wired R/C (Option: 30m long cable compatible) |
| Audio |
None |
| Input signal compatability |
WUXGA/UXGA/WSXGA+/SXGA+/SXGA/WXGA/XGA/SVGA/VGA/MAC
1080p-24/25/30/48/50/60; 1080psf-24/25/30; 1080i-50/60; 720p-50/60/575p/480p/575i/480i (depends on input) |
| Colour systems |
PAL / SECAM / NTSC / NTSC4.43 / PAL-M /PAL-N |
| Scanning frequency |
H/V sync 15~120kHz/48~120Hz Dot clock 230 MHz |
| Fan noise |
36dB (Eco1) |
| Voltage |
100-120V/200-240V AC (auto voltage) |
| Dimensions (W x H x D) |
400 x 242.5 x 523.5 mm |
| Weight |
19.8kg |
