Image size:
|
24x36mm
|
Macro feature:
|
None
|
Zoom type:
|
|
6-group linear zoom (zoom extension: 79.6mm) |
|
Front of lens barrel moves |
|
Lens mount type:
|
Canon EF mount
|
Focal length, aperture ratio:
|
100-400mm, 1:4.5-5.6
|
Minimum focusing distance:
|
1.8m
|
Manual focusing:
|
Set focus mode switch, operate manual focusing ring (full-time mechanical manual focusing system)
|
Dimensions and weight:
|
92mm diameter x 189mm, 1360g (prototype weight)
|
Magnification:
|
|
At 100mm - 0.06x |
|
At 400mm - 0.20x |
|
Angle of view at infinity:
|
|
Diagonal (43.2mm) - 24-6 |
|
Vertical (24mm) - 14-3 |
|
Horizontal (36mm) - 20-5 |
|
Field:
|
|
At 100mm - 393x591 |
|
At 400mm - 119x177 |
|
Coating:
|
Super spectra coating
|
Filter size:
|
77mm diameter, P=0.75mm. (Up to 1 filter attachable)
|
Lens configuration:
|
17 elements in 14 groups (fluorite element for G3, Super UD glass for G7)
|
Aperture blades:
|
8
|
Aperture control:
|
Pulse control with EMD (enabled simultaneously with AF drive)
|
Aperture value/indicator:
|
Maximum: f/4.5-5.6 (indicator on lens barrel), Minimum: f/32-38 (f/32-40 for lenses featuring 1/3-stop increments
|
Rotation angle:
|
62
|
Drive system:
|
Ring USM drive
|
Drive noise:
|
40dB or less (based on Canon's Standard Test Method)
|
Drive speed:
|
H/0.54 to L/1.67 seconds or shorter (lens drive speed from infinity to minimum focusing distance)
|
Depth of field markings:
|
None
|
Signal transmission:
|
|
EOS signal transmission, including 5 types of information (including absolute distance information) |
|
1 - Lens mode |
|
2 - Lens type |
|
3 - Metering information |
|
4 - Focal length |
|
5 - AF drive information |
|
Focusing range:
|
1.8m to infinity (at all focal lengths)
|
Infrared index:
|
Provided
|
Focusing extension mechanism:
|
Rear-focusing method, with focusing cam operating the floating elements, groups 4 and 6
|
Focusing distance limiting switch:
|
|
Two focusing distance ranges can be set |
|
1 - 1.8m-infinity |
|
2 - 6.5m-infinity |
|
