Feature |
Specification |
Projection System |
DLP |
Display Panel |
0.55" DarkChipTM 3 DMD |
Resolution |
Native:
Maximum:
- UXGA (1,600 x 1,200)
1080p (1,920 x 1,080)
|
Video Compatibility |
NTSC (3.58/4.43), PAL (B/D/G/H/I/M/N), SECAM (B/D/G/K/K1/L), HDTV (720p, 1080i, 1080p), EDTV (480p, 576p), SDTV (480i, 576i) |
Aspect Ratio |
Native:
Supported:
|
Contrast Ratio |
4,200:1 |
Displayable Colors |
1.07 Billion Colors |
Brightness |
2,500 ANSI Lumens (Standard) 2,000 ANSI Lumens (ECO) |
Projection Lens |
F = 2.65, f = 3.50mm Manual Focus |
Projection Screen Size (Diagonal) |
60" (152cm) ~ 300" (762cm) |
Projection Distance |
1.0" (2.4cm) ~ 59" (149cm) |
Throw Ratio |
77"@13cm (0.30:1) |
Horizontal Refresh Scan Rate |
30k ~ 100k Hz |
Vertical Refresh Scan Rate |
50 ~ 120 Hz |
Lamp Type |
Philips 230 W user replaceable UHP lamp |
Lamp Life |
3,500 Hours (Standard), 5,000 Hours (ECO) |
Keystone Correction |
+/-15 Degrees (Vertical ), Manual |
Projection Mode |
Front, Rear, Front-Ceiling, Rear-Ceiling |
Ceiling Mounting Capability |
Yes |
Audio |
20 watts speaker (Two internal speaker with 10 watts output) |
Weight |
15.4 lbs (7.0Kg) |
Dimensions (W x D x H) |
422 x 345 x 140 mm (16.6" x 13.6" x 5.5") |
Remote Control |
IR remote control with laser pointer & PgUp/PgDn functions |
Digital Zoom |
2X |
PIP |
N/A |
Lens Shift |
N/A |
Power Supply |
AC input 100~240V auto-switching power supply |
Power Consumption |
380 Watts (Operation), <1 Watts (Standby, LAN off) |
Operating Temperature |
5C ~ 35C / 41F ~ 95F |
Operating Humidity |
80%RH (Max.) |
Noise Level |
33 dBA (Standard mode), 27 dBA (ECO mode) |
I/O Connectors |
Input:
- Analog RGB/Component Video (D-sub) x 2
- Composite Video (RCA) x 1
- S-Video (Mini DIN) x 1
- HDMI (Video, Audio, HDCP) x 2
- PC Audio (Stereo mini jack) x 2
- USB (Type A) x 2
- USB (Mini-B) x 1
- Mic In (Stereo mini jack) x 1
Output:
- Analog RGB (D-sub) x 1
- PC Audio (Stereo mini jack) x 1
|
Control Interface |
- USB (Mini-B) x 1, shared with the one of Input Interface
- RS232 (Mini DIN) x 1
- 12V DC (Screen control) x 1
|
Network Interface |
Ethernet port (RJ45) x 1 |
Other Features |
Low Noise Level Ultra-Short Throw Distance (With reflection mirror) Acer ColorBoost Technology Acer ColorBoost II Technology Acer ColorBoost II+ Technology Acer SmartFormat Technology Acer EcoProjection Technology ColorSafe II Empowering Key Acer eTimer Management Acer eOpening Management Acer eView Management Wall-Color Compensation Acer ePower Management High Altitude Mode Acer Top-Loading Lamp Design Installation Menu Digital Connectivity-HDMI Dual D-Sub Input Multi-PC Connectivity Instant Pack Auto Shutdown Quick Start Smart Detection PIN Security Digital Zoom and Pan ECO Mode Loop Through Alarm Built-in Speakers RS-232 15 Vertical Keystone Correction 3X Color Wheel Rotation Speed Closed Captioning Instant Resume DLP 3D ready True 24p USB Slide Show (Photos, PowerPoint*) Display over USB (DoUSB) Crestron Network Control (LAN & Wireless*) Remote Desktop Smartphone Projection (MobiShow), w/o HD Video (Optional*) |
|
|
