| Performance |
|---|
| PTZ modes | 5 Pattern, 8 Tour, Auto scan, Preset point |
| PTZ protocols | DH-SD |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Indoor & outdoor |
| Auto-tracking | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Built-in light | Yes |
| Design |
|---|
| Form factor | Spherical |
| Product colour | White |
| Mounting type | Ceiling |
| International Protection (IP) code | IP66 |
| Camera |
|---|
| Tilt preset speed | 150 °/sec |
| Pan preset speed | 240 °/sec |
| Tilt angle range | -20 - 90 ° |
| Pan range | 0 - 360 ° |
| White balance | Auto, Indoor, Manual, Natural, Outdoor, Sodium lamp, Street lamp |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/1 - 1/30000 s |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, horizontal | 51.9 - 3 ° |
| Lens viewing angle, vertical | 39.7 - 2.2 ° |
| Lens viewing angle, diagonal | 63.1 - 3.7 ° |
| Tilt manual speed | 0 - 90 °/sec |
| Pan manual speed | 0 - 240 °/sec |
| Number of Privacy masking areas | 24 |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Lens system |
|---|
| Maximum aperture number | 3.6 |
| Auto focus | Yes |
| Closest focusing distance | 0.1 m |
| Detect distance | 2500 m |
| Observe distance | 987.5 m |
| Recognize distance | 500 m |
| Identify distance | 250 m |
| Minimum aperture number | 1.6 |
| Zoom capability | Yes |
| Optical zoom | 25x |
| Digital zoom | 16x |
| Focal length range | 5 - 125 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 150 m |
| LED type | IR/White |
| Number of illumination LEDs | 4 |
| Video |
|---|
| Noise reduction | Yes |
| Privacy masking | Yes |
| Image stabilizer | Yes |
| Gain control type | Auto/Manual |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Bit rate | H264: 96 kbps—14848 kbps H265: 38 kbps—8960 kbps |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 2D noise reduction, 3D noise reduction |
| Maximum resolution | 2560 x 1440 pixels |
| Supported graphics resolutions | 352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2304 x 1296, 2560 x 1440 |
| Video compression formats | H.264, H.264+, H.264B, H.264H, H.265, H.265+, M-JPEG |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 4 MP |
| Audio |
|---|
| Audio input channels | 1 channels |
| Audio output channels | 1 channels |
| Signal-to-Noise Ratio (SNR) | 55 dB |
| Audio formats supported | G.711 A-law, G.722.1, G.723, G.726, G.729 |
| Network |
|---|
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Number of users | 20 user(s) |
| Streaming method | Multicast, Unicast |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | FTP;RTMP;IPv6;Bonjour;IPv4;DNS;RTCP;PPPoE;NTP;RTP;8 02.1x;HTTPS;SNMP;TCP/IP;DDNS;UPnP;NFS;ICMP;UDP;IG MP;HTTP;SSL;DHCP;SMTP;Qos;RTSP;ARP |
| Storage |
|---|
| ROM capacity | 4096 MB |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Built-in HDD | No |
| Maximum memory card size | 512 GB |
| Internal memory | 1024 MB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Video motion detection | Yes |
| Alarm input channels | 2 |
| Alarm output channels | 1 |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (typical) | 13 W |
| Power consumption (max) | 23 W |
| DC output voltage | 24 |
| DC output current | 2.5 A |
| Operational conditions |
|---|
| Operating temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Height | 325.3 mm |
| Diameter | 20.2 cm |
| Weight | 4.6 kg |
| Package weight | 7.13 kg |
| Packaging content |
|---|
| Number of cameras | 1 |
| Technical details |
|---|
| Sustainability certificates | CE, Federal Communications Commission (FCC) |
| Other features |
|---|
| Video compression formats | H.264, H.264+, H.264B, H.264H, H.265, H.265+, M-JPEG |
