Display
|
Display Technology:
0.2" DLP |
|
Light Source: R/G/B
LED |
|
Light Source Life
(max): 30000 hours |
|
True Resolution
(native): WVGA(854x480) |
|
Light Output (max): 150
lumens |
|
Contrast Ratio:
3500:1 |
|
Color Saturation
:100%(NTSC) |
|
Display Colors
:16.7M |
|
|
Projection Lens
|
Throw Ratio:
1.4 |
|
Projection Distance:
0.5 ~3.7 meters |
|
Projection/Screen Size:
16 ~120 inchs |
|
Projection Offset:
100% |
|
Zoom Ratio:
Fixed |
|
|
Video Feature
|
Keystone adjustment:
Digital (Up to +/- 40 degree) |
|
Auto Keystone:
Yes |
|
Aspect Ratio: Auto/4:3
/16:9 |
|
Projector Placement:
Front Table/Front Ceiling/Rear Table/Rear Ceiling |
|
|
Audio Features
|
Built-in Speaker: 2 W x
1 |
|
|
Power
|
|
Power
Consumption |
Power On Mode: 24
W |
|
Standby Mode: <0.5
W |
Internal
Battery |
5 V, 6000 mAh, Battery
life: 5 hours @ 50 lumens *1 |
Noise Level
|
30 dB(Standard mode)/
28 dB (Theater mode) |
|
|
Interface
|
|
Signal
Input |
HDMI,
MHL |
Audio
Output |
Earphone
out |
USB Port
|
1 x Type A port,
*2 |
Mechanical Design
|
Chassis Colors:
Silver |
|
On-machine Buttons:
Yes, () |
|
Tripod Socket:
Yes |
|
|
Dimensions
|
Physical
Dimension(WxHxD):110 x 29 x 83 mm |
|
Box Dimension
(WxHxD):170 x 135 x 95mm |
Weight
|
Net Weight
(Esti.):307g |
|
Gross Weight
(Esti.):880g |
Operation
Temperature |
0~40 |
Operation Humidity
|
20-90% |
|
|
Accessories
|
Carrying
Bag |
|
HDMI
cable |
|
Power
Adapter |
|
Quick Start
Guide |
|
Warranty
card |
|
AC
plug |
|
|
Compliance and
Standards |
CB, CE,FCC,VCCI, CU,
C-Tick, CCC, PSE,IEC62471,CEC |
|
|
Note
|
*1. The battery has a
lifespan and ages every time when it is charged and discharged. It will
gradually loose its charging capability as it
ages. |
|
*2. for power charge
usage |
