GENERAL:
|
Magnification:
|
|
12x
|
Objective lens diameter:
|
|
Effective 36mm
|
Real field of view:
|
|
5 (Field of view at 1000m: 87.5m)
|
OPTICAL CONSTRUCTION:
|
Lens construction:
|
|
|
Objective lens: 2 elements in 1 groups |
|
Eyepiece lens: 5 elements in 4 groups |
|
Exit pupil diameter:
|
|
3.0mm
|
Eye relief:
|
|
14.5mm
|
Prism type:
|
|
Porro II prism
|
Pupil-distance adjustment range:
|
|
55mm-75mm
|
FOCUSSING AND DIOPTRIC CORRECTION:
|
Focusing system:
|
|
Objective lens movement
|
Focusing method:
|
|
Manual focusing by turning the focusing knob
|
L-R dioptric correction method:
|
|
Adjustable with the right eyepiece lens
|
L-R dioptric correction range:
|
|
3.0 dioptres
|
Closest focusing distance:
|
|
6m
|
IMAGE STABILIZER:
|
Image Stabilizer system:
|
|
Optical correction with Vari-Angle Prism
|
Correction angle:
|
|
0.8
|
Shake detection system:
|
|
Two shake gyro sensors
|
Image Stabilizer continuous operation time:
|
|
+25C: approx. 4 hours; -10C: approx. 20 minutes (using AA-size alkaline batteries)
|
DIMENSIONS (WxDxH):
|
|
127 x 174 x 70mm
|
WEIGHT:
|
|
660g (body only)
|
OPERATING ENVIRONMENT:
|
|
-10C to 45C; 90% humidity
|
STANDARD ACCESSORIES:
|
|
Dedicated soft case, strap, objective lens caps, eyepiece lens caps
|
POWER SOURCE:
|
|
2x AA batteries
|
All data based on Canon's Standard Test Method:
|
Subject to change without notice:
|
