General |
|
|
Panel Type |
0.76" LCD panel x 3 |
|
Lamp |
N.A. |
|
Brightness |
6,500 lumens |
|
Lens |
F1.7-2.3, f26.8-45.5mm (powered zoom: 1.6-2.8:1) |
|
Contrast (Full on / Full off) |
3,000,000:1 |
|
Resolution (Native / maximum) |
WXGA |
|
Screen Size |
40" - 400" |
|
Lens Shift |
Vertical ±67%, horizontal ±35% |
|
Keystone Correction Range |
Vertical ±35° or horizontal ±35° |
|
Weight |
approximately 16.9kg |
|
Dimensions (W x H x D) |
560 x 205 x 443.2 mm |
|
Power Consumption |
505W |
|
Terminals |
HDMI in (19-pin x 1) |
|
|
RGB1&2 in (D-sub HD 15-pin x 1, 5BNC x 1) |
|
|
Video in (Pin Jack x 1) |
|
|
Monitor out (D-sub 15-pin x 1) |
|
|
Audio in (Pin jack x 2, M3 x 2) |
|
|
Audio out (M3 x 1) |
|
|
Serial in (D-sub 9-pin x 1) |
|
|
Remote In x2 (M3 x 1),(D-sub 9-pin x 1) |
|
|
LAN (RJ-45 x 1) |
|
|
Digital Link (RJ-45 x 1) |
|
|
Memory Viewer/Pairing (USD type A x 1) |
|
|
DC out (USB Type A x 1, DC5 5 V/S A) |
|
Optional Accessories |
ET-PKE301B (Bracket assembly) |
|
|
ET-PKE200H (High ceiling mount bracket) |
|
|
ET-PKE200S (Low ceiling mount bracket) |
|
|
ET-RMF100 (Replacement filter unit |
|
|
ET-WM300 (Wireless module) |
|
|
|
|
Optional Lens |
|
|
Zoom lens |
ET-ELW22 (0.8-1.0:1) |
|
|
ET-ELW20 (1.2-1.7:1) |
|
|
ET-ELT20 (2.7-4.5:1) |
|
|
ET-ELT21 (4.4-7.1:1) |
|
Fixed focus lens |
ET-ELW21 (0.8:1) |
|
Standard Accessories |
Software CD-ROM |
|
|
Wireless / wired remote control & batteries |
|
|
Power cord |
