| Specifications |
| |
GV-5016 |
GV-5016 x 2 |
| Interface |
PCI-E (x1) |
PCI-E (x1) x 2 |
| Input Type |
LFH |
| Video Input |
16 Cams |
32 Cams |
| Audio Input |
16 Channels |
32 Channels |
| Recording Rate (D1) |
NTSC |
480 fps |
960 fps |
| PAL |
400 fps |
800 fps |
| Display Rate |
NTSC |
480 fps |
960 fps |
| PAL |
400 fps |
800 fps |
| Video Resolution |
NTSC |
H/W |
704 x 480 |
704 x 480 |
| S/W |
352 x 240 |
352 x 240 |
| PAL |
H/W |
704 x 576 |
704 x 576 |
| S/W |
352 x 288 |
352 x 288 |
| Video Compression Format |
S/W |
Geo MPEG4, Geo H264 |
| H/W |
H264 |
| Audio Compression Format |
AAC (16 kHz / 16 bit) |
| Bit Rate Range |
5M ~ 10M |
| GV-Multi Quad Card Support |
No |
| GV-Loop Through Card Support |
No |
| GV-NET/IO Card Support |
Yes (Note 3) |
| Dimensions (W x H) |
168 x 70 mm / 6.61 x 2.75 in |
| Installation Guide |
GV-5016 |
|
Note:
1. GV-5016 does not support the TV-Out function.
2. GV-5016 is currently not compatible with VIA series and ATI series chipset motherboards.
3. To work together with GV-5016, GV-NET/IO Card V3.1 must be set in the I/O Box Mode and connected to the PC through USB or DB9.
4. Specifications are subject to change without notice.
|
|
Minimum System Requirements For One Card
|
| OS Supported |
32-bit |
Windows XP / Windows Vista / Windows 7 / Windows Server 2008 |
| 64-bit |
Windows 7 / Windows Server 2008 R2 |
| CPU |
Core 2 Quad, 2.4 GHz |
| RAM |
2 x 1 GB Dual Channels |
| HDD |
500 GB |
| Graphic Card |
AGP or PCI-Express, 800 x 600 (1280 x 1024 recommended),
32-bit color |
| DirectX |
9.0c |
|
Minimum System Requirements For Two Cards
|
| OS Supported |
32-bit |
Windows XP / Windows Vista / Windows 7 / Windows Server 2008 |
| 64-bit |
Windows 7 / Windows Server 2008 R2 |
| CPU |
Core i5 650, 3.20 GHz |
| RAM |
2 x 1 GB Dual Channels |
| HDD |
1 TB |
| Graphic Card |
AGP or PCI-Express, 800 x 600 (1280 x 1024 recommended),
32-bit color |
| DirectX |
9.0c |
