Camera
|
|
Image Sensor
|
1/3" progressive scan CMOS
|
|
Picture Elements
|
1280 (H) x 1024 (V)
|
|
Minimum Illumination
|
Color
|
0.15 Lux (1/30 sec), 0.08 Lux (1/5 sec)
|
|
B/W
IR ON
|
0 Lux
|
|
Shutter Speed
|
Automatic, Manual (1/5 ~ 1/8000 sec)
|
|
White Balance
|
Automatic, Manual (2800K ~ 8500K)
|
|
Lens
|
|
Megapixel
|
Yes
|
|
Day / Night support
|
Yes
|
|
Max Aperture
|
F/1.3 5%
|
|
Focal Length
|
2.7 ~ 9 mm
|
|
Field of view
|
Diagonal
|
126 (W) ~ 38.2 (T) 5
|
|
Horizontal
|
98.5 (W) ~ 29.8 (T) 5 |
|
Vertical
|
78.7 (W) ~ 23.9 (T) 5
|
|
Operation
|
Focus
|
Manual (w / lock)
|
|
Zoom
|
Manual (w / lock)
|
|
Iris
|
DC
|
|
IR LED Quantity
|
15 IR LEDs
|
|
IR Distance
|
15 m / 50 ft (Max.)
|
|
Operation
|
|
Video Codec
|
H.264, MPEG4, MJPEG
|
|
Video Streaming
|
Dual Streams from two of H.264, MPEG4 and MJPEG
|
|
Frame Rate
|
30 fps at 1280 x 1024
* The frame rate and the performance may vary depending on the number of connections and data bitrates (different scenes).
|
|
Image Setting
|
Brightness, Contrast, Sharpness, Gamma, White Balance, Flicker-less, Image Orientation, Backlight Compensation
|
|
Audio Codec
|
G.711, AAC (16 kHz / 16 bit)
* AAC is only supported by GV-System V8.5 or later
|
|
Sensor Input
|
1 Input (Dry Contact)
|
|
Alarm Output
|
1 Digital Output
|
|
Video Resolution
|
|
Main Stream
|
4:3
|
1280 x 960, 640 x 480, 320 x 240
|
|
16:9
|
1280 x 720, 640 x 360, 448 x 252
|
|
5:4
|
1280 x 1024, 640 x 512, 320 x 256
|
|
Sub Stream
|
4:3
|
640 x 480, 320 x 240
|
|
16:9
|
640 x 360, 448 x 252
|
|
5:4
|
640 x 512, 320 x 256
|
|
Network
|
|
Interface
|
10/100 Ethernet
|
|
Ethernet Protocol
|
HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, RTSP, PSIA, SNMP, QoS (DSCP)
|
|
Mechanical
|
|
Lens Mounting
|
14 mm
|
|
Rotation Axis
|
3-axis (pan / tilt / roll)
|
|
Connectors
|
Power
|
3-pin terminal block
|
|
Ethernet
|
RJ-45
|
|
Audio
|
1 In (RCA female for microphone)
1 Out (RCA female for speaker)
|
|
Digital I/O
|
I/O Wires
|
|
Auto Iris
|
DC drive
|
|
Local Storage
|
Micro SD/SDHC memory card slot
|
|
TV-Out
|
BNC connector
* The TV-Out function only works in 640 x 480 resolution. For TV-Out to work properly, you must set the video resolution to 1280 x 1024 or lower. If both streams are enabled, the Sub Stream must be set to 640 x 480.
|
|
General
|
|
Operating Temperature
|
-20 C ~ 50 C / 4 F ~ 122 F
|
|
Humidity
|
10% to 90% (no condensation)
|
|
Power Source
|
12V DC / 24V AC / PoE
|
|
Power Consumption
|
12 W (max. 1A at 12V DC)
|
|
Regulatory
|
CE, FCC, C-Tick, RoHS compliant
|
|
Dimensions
|
165 x 125 mm / 6.49 x 4.92 in
|
|
Weight
|
1.7 kg / 3.75 lb
|
|
Protection Classification
|
IP66
|
|
Vandal Resistance
|
GV-120D / GV-121D
|
IK10+
|
|
GV-122D / GV-123D
|
IK7
|
|
Power over Ethernet
|
|
PoE Standard
|
IEEE 802.3af Power over Ethernet / PSE
|
|
PoE Power Supply Type
|
End-Span
|
|
PoE Power Output
|
Per Port 48V DC, 350mA. Max. 15.4 watts
|
|
Web Interface
|
|
Installation Management
|
Web-based configuration
|
|
Maintenance
|
Firmware upgrade through Web Browser or Utility
|
|
Access from Web Browser
|
Camera live view, video recording, change video quality, bandwidth control, image snapshot, digital I/O control, audio, Picture in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Wide Angle Lens Dewarping
|
|
Language
|
Czech / Danish / English / French / German / Hebrew / Hungarian / Italian / Japanese / Polish / Portuguese / Russian / Serbian / Simplified Chinese / Spanish / Traditional Chinese
|
|
Applications
|
|
Network Storage
|
GV-NVR, GV-System
|
|
3G Mobile Phone
|
Built-in player for 3GPP / ISMA
|
|
Live Viewing
|
IE , Mobile Phone
|
|
CMS Server support
|
GV-Control Center, GV-Center V2, GV-VSM, GV-Backup Center, GV-Video Gateway, GV-Recording Server
|
