Video |
Video Standard |
NTSC, PAL |
Video Input |
2 channels |
Compression |
H.264, MPEG 4, MJPEG |
Frame Rate (at Full D1 resolution)
|
NTSC |
30 fps per channel; 60 fps in total |
PAL |
25 fps per channel; 50 fps in total |
Resolution |
Full D1, Half D1, CIF, QCIF |
Video Streaming |
Configurable frame rate and bandwidth, Constant and variable bitrate |
Video Adjustment |
Brightness, Contrast, Hue, Saturation, Image Quality,Image Size, Bitrate, GOP (Group of Picture) size |
Audio |
Audio Input |
2 channels |
Compression |
G.711 |
Management |
Event Management |
Trigger |
Schedule, Sensor Input, Motion Detection |
Action |
Store Video (AVI format), Email with captured images, Captured images uploaded over FTP, Monitoring by Center V2, VSM and GV-GIS, Relay outputs to control external devices |
Firmware Upgrade |
Remote upgrade by HTTP, Firmware upgrade utility included in the Software DVD |
Storage |
Mass storage through USB (optional) |
Client PC Requirements |
Microsoft IE 6.x or above running on Windows 2000/XP/2003/Vista |
Security |
IP address filtering |
Network |
Interface |
10/100 Base-T Ethernet, 802.11b/g, 802.11n Wireless LAN (optional) Mobile broadband: UMTS, EDGE, etc. (optional) |
Protocol |
HTTP, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS |
Connector |
Video Input |
BNC 2 ports |
Audio Input |
RCA 2 ports |
Audio Output |
RCA 1 port |
Terminal Block |
RS-232 interface for GPS |
RJ-45 Connector |
2 digital inputs, 2 relay outputs, RS485 |
Ethernet |
RJ-45, 10/100 Mbps |
USB 2.0 |
2 ports |
Power |
Power Jack |
1 DC-In power jack |
Input |
100-240V, 1.2A, 50-60 mHz |
Output |
12V, 3A, (36W Max.) |
Power over Ethernet |
PoE Standard |
IEEE 802.3af Power over Ethernet / PSE |
PoE Power Supply Type |
End-Span |
PoE Power Output |
Per Port 48V DC, 350mA. Max. 15.4 watts |
Alarm |
Sensor Input |
2 inputs |
Alarm Output |
2 outputs |
Environment |
Operation Temp. |
-20 ~ 55 C / -4 ~ 131 F |
Humidity |
0 ~ 85% RH (non-condensing) |
Physical |
Dimensions (L x W x H) |
123 x 106 x 25 mm / 4.84 x 4.17 x 0.98 in |
Weight |
0.345 kg / 0.76 lb (Net) |
