| Video |
| Video Standard |
NTSC, PAL |
| Video Input |
4 channels |
| Compression |
MPEG4 |
|
Frame Rate
(at Full D1 resolution)
|
NTSC |
30 fps per channel; 120 fps in total |
| PAL |
25 fps per channel; 100 fps in total |
| Resolution |
Full D1, Half D1, CIF, QCIF |
| Video Streaming |
Configurable frame rate and bandwidth,
Constant and variable bitrate, |
| Video Adjustment |
Brightness, Contrast, Hue, Saturation, Image Quality,Image Size, Bitrate, GOP (Group of Picture) size |
| Audio |
| Audio Input |
4 channel |
| Compression |
G.723 |
| Management |
| Event Management |
Trigger |
Schedule, Time, Sensor Input, Motion Detection |
| Action |
Store Video (AVI format),
Email with captured images,
Captured images uploaded over FTP,
Monitoring by Center V2, VSM and GV-GIS,
Relay outputs to control external devices |
| Firmware Upgrade |
Remote upgrade by HTTP,
Firmware upgrade utility included in the Software DVD |
| Storage |
Mass storage through USB (optional) |
| Client PC Requirements |
Microsoft IE 6.x or above running on Windows 2000/XP/2003/Vista |
| Security |
IP address filtering |
| Network |
| Interface |
10/100 Base-T Ethernet,
802.11b/g, 802.11n Wireless LAN (optional)
Mobile broadband: UMTS, EDGE, etc. (optional)
|
| Protocol |
HTTP, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, Multicast |
| Connector |
| Video Input |
4 BNC ports |
| Audio Input |
2 stereo phone jacks to 4 RCA ports |
| Audio Output |
1 RCA port |
| Terminal Block |
4 digital inputs, 4 relay outputs, RS485, 1 Wiegand interface,
1 UART interface |
| Ethernet |
RJ-45, 10/100 Mbps |
| USB 2.0 |
2 ports |
| Power |
Power Jack |
1 DC-In power jack, 1 DC-Out power jack |
| Input |
100-240V, 1.2A, 50-60 mHz |
| Output |
12V, 3A, (36W Max.) |
| Power over Ethernet |
| PoE Standard |
IEEE 802.3af Power over Ethernet / PSE |
| PoE Power Supply Type |
End-Span |
| PoE Power Output |
Per Port 48V DC, 350mA. Max. 15.4 watts |
| Alarm |
| Sensor Input |
4 inputs |
| Alarm Output |
4 outputs |
| Environment |
| Operation Temp. |
-20 ~ 55 C / -4 ~ 131 F |
| Humidity |
0 ~ 85% RH (non-condensing) |
| Physical |
| Dimensions (L x W x H) |
174 x 145 x 40 mm / 6.85 x 5.7 x 1.57 in |
| Weight |
0.73 kg / 1.61 lb (Net) |
