| Image Sensor |
12 Megapixels (effective), 1/2.3" |
| Focal Length/Lens Configuration |
6.3 18.9mm (36 108mm equivalent in 35mm photography), 6 Lenses in 5 Groups, 4 Aspherical Lenses, 6 surfaces |
| Zoom |
3x Optical Zoom + 4x Digital Zoom |
| Aperture Range |
f3.1 (W) / f5.9 (T) |
| Display |
2.7" LCD with Backlight Boost, approx. 230,000 dots 2 Steps Brightness Adjustment |
| Viewfinder |
N/A |
| Focus System |
CCD Contrast Detection |
| Focus Range (from lens surface) |
Normal mode: 23.6" infinity (0.6m infinity)
Macro mode (Wide): 7.9" infinity (0.2m infinity)
Macro mode (Tele): 23.6" infinity (0.6m infinity)
Super Macro mode: 0.2" infinity (.5cm infinity) |
| Focus Mode |
iESP Auto, Spot AF, Face Detection AF, AF Tracking |
| Shutter Speed |
1/2000 sec. 1/2 sec. (up to 4 sec. in Candle Scene mode) |
| ISO Sensitivity (SOS: Standard Output Sensitivity) |
Auto, 80, 100, 200, 400, 800, 1600 |
| Exposure Metering |
Digital ESP Metering, Face Detection AE (when Face Detection AF is selected) |
| White Balance Control |
Auto, Overcast, Sunlight, Tungsten, Flourescent 1,2,3 |
| Exposure Compensation |
2 EV steps in 1/3 EV steps |
| Image File Format |
Still Image: JPEG
Movie: AVI Motion JPEG |
| Shooting Modes |
20 Shooting Modes;
Intelligent Auto, Program Auto, Digital Image Stabilization, Magic Filter, Scene Modes (1. PORTRAIT, 2. LANDSCAPE, 3. NIGHT SCENE. 4. NIGHT+PORTRAIT, 5. SPORT, 6. INDOOR, 7. CANDLE, 8. SELF PORTRAIT, 9. SUNSET, 10. FIREWORKS, 11. CUISINE, 12. DOCUMENTS, 13. PET), Movie
Magic Filter(Pop Art, Pinhole, Wedding) |
| Panorama |
Up to 10 frames automatically stitchable with OLYMPUS Master software |
| Continuous Shooting |
N/A |
| Shooting Assist Functions |
Frame Assist |
| Image Processing |
N/A |
| Noise Reduction |
Set automatically at shutter speeds of 0.5 second or longer in specific scene modes |
| Image Playback |
Still Image: Single, Index Display (4/9/16/25), Up to 10x Enlargement, Slideshow, Rotation
Movie: Normal, Fast-Forward, Reverse, Frame-by-Frame, |
| Playback Edit Effects |
Still Image: Red-Eye Fix, Lighting Fix, Resize, Cropping |
| Flash |
Built-in |
| Flash Modes |
Auto (for low light and backlit conditions)
Red-Eye Reduction
Fill-in
Off |
| Flash Working Range |
Wide: 0.66ft (0.2m) 13.8ft (4.2m) at ISO 800
Tele: 2.0ft (0.6m) 7.9ft (2.4m) at ISO 800 |
| Self-Timer |
12 Seconds |
| Memory |
19MB Internal Memory |
| Removable Media Card |
xD-Picture Card (1GB, 2GB), microSD (MASD-1 is required) |
| Outer Connectors |
USB Connector |
| Auto-Connect USB |
USB 2.0 High-Speed (USB Mass Storage) |
| System Requirements |
Auto-Connect USB: Windows 2000/XP/VISTA with USB port, Mac OS X 10.3 or later with USB port
Software: Windows 2000PRO/XP/VISTA, Mac OS X 10.3 - 10.5 |
| Operating Temperature/Humidity |
Operation: 32 104F (0 40C), 30% - 90% humidity
Storage: -4 140F (-20 60C), 10% - 90% humidity |
| Power Source |
AAx2 |
| Battery Life (CIPA DC-002) |
180 Shots |
| Dimension |
3.78"W x 2.44"H x 1.05"D (96.0 mm x 62.1 mm x 26.71 mm) |
| Weight |
4.1oz (117g) without batteries and media card |
