Nikon Laser 550AS Rangefinder
Applications
Hunting
|
Sailing
|
Exploring ruins
|
Golfing or caddying
|
Forestry surveys
|
Features:
- Easy operation enables measurement of horizontal distances, height, angle and vertical separation (difference in height between two targets), in addition to the actual distance measurement function.
- The results are displayed on both an internal and an external LCD panel. The external panel shows all results simultaneously.
- Select from two measurement modes (Target Priority Switch System):
- First Target Priority mode displays the range to the nearest target among multiple results obtained with a single measurement - useful when measuring the distance to a pin on a green with woods in the background.
Distant Target Priority mode displays the range to the farthest target among multiple results obtained with a single measurement - useful when hunting in heavily wooded areas.
- Measurement range: 10-500m/11-550 yd.
- Actual Distance measurement display step is 0.5m/yd. (shorter than 100m/yd.)
- High-quality 6x monocular with multilayer coating for bright, clear images
- High-eyepoint design affords eyeglass wearers easy viewing
- Compact, lightweight design enables easy, single-hand operation
- Diopter adjustment function
- Capable of distancing different targets in succession by keeping the button pressed
- Waterproof (up to 1 metre for 10 minutes), but not for underwater usage; the battery chamber is water resistant.
- Wide temperature tolerance: -10ºC to +50ºC
Internal display
- Actual (linear) Distance
- Horizontal Distance
- Height
- Angle
- Height between two points
- First Target Priority mode
- Distant Target Priority mode
- Battery condition
- Distance
- Unit of measure (m/yd.)
- Target mark ()
- Laser irradiation ()
External display
- Measurement unit (m/yd.)
- Height
- Actual (linear) Distance
- Horizontal Distance
- Angle (º)
Example
*The above calculation is an example of equation. The displayed measurement results can be utilised based on the user's consideration and include other usage than distance estimation.
Specifications
| |
|
Laser 550A S |
|
| Measurement range |
|
Distance:10-500m/11-550 yd.
Angle: 89 |
|
| Distance display (Increment) |
|
[Internal Display]
Act (Actual Distance):
every 0.5m/yd. (shorter than 100m/yd.)
every 1.0m/yd. (greater than 100m/yd.)
Hor (Horizontal Distance) and Hgt (Height):
every 0.2m/yd. (shorter than 100m/yd.)
every 1.0m/yd. (greater than 100m/yd.)
Ang (Angle):
every 0.1 (less than 10)
every 1.0 (more than 10)
*Downward angle from the horizontal line: with display "-"
[External Display]
Act (Actual Distance): every 0.5m/yd.
Hor (Horizontal Distance) and Hgt (Height):every 0.2m/yd.
Ang (Angle): every 0.1 |
|
| Finder |
|
Magnification (x) |
|
6 |
|
| Effective objective diameter (mm) |
|
21 |
|
| Actual field of view () |
|
6.0 |
|
| Exit pupil (mm) |
|
3.5 |
|
| Eye relief (mm) |
|
18.2 |
|
| Dimensions (LxHxW) (mm) |
|
130x69x45 |
|
| Weight (g) (excluding battery) |
|
210 |
|
| Power source |
|
CR2 lithium battery x 1 (DC3V)
Auto power shutoff function equipped (after 30 sec.) |
|
| Safety and EMC |
|
VCCI class B, Class 1M laser product (IEC60825-1:2001),
Class 1 laser product (21CFR 1040.10 and 1040.11) CE,
EMC directive, Fcc Part15 subpart B Class B, c-tick, WEEE |
The specifications of the product may not be achieved depending on the target object's shape, surface texture and nature, and/or weather conditions.
